Need help with setting up crossover frequency for my yamaha NS-AP2600 5.1 speakers


  • You cannot start a new topic
  • Please log in to reply
7 replies to this topic

#1 of 8 kenkraly20212

kenkraly20212

    Agent

  • 45 posts
  • Join Date: May 26 2012

Posted July 07 2012 - 04:55 PM

I need some help with setting up crossover frequency for my yamaha speakers 5.1. I have a Onkyo TXSR-308 Home theater receiver and Yamaha 5.1 Speakers model number NS-AP2600. What is the correct cross over frequency I set the onkyo to for the speakers? Any help on this would be great. Thanks.

#2 of 8 Al.Anderson

Al.Anderson

    Screenwriter

  • 2,118 posts
  • Join Date: Jul 02 2002
  • Real Name:Al

Posted July 07 2012 - 10:09 PM

You don't mention having a sub. If you don't have a sub then set the mains to 'large', which in effect means there's no crossover. If you do have a sub, then set the mains to small, and set the crossover at 100hz (since the 2600's have a frequency response starting at 90hz, and there's a slope involved in the crossover setting). It couldn't hurt to also try 120hz and compare the two to see which one you like more.

#3 of 8 kenkraly20212

kenkraly20212

    Agent

  • 45 posts
  • Join Date: May 26 2012

Posted July 08 2012 - 07:26 AM

You don't mention having a sub. If you don't have a sub then set the mains to 'large', which in effect means there's no crossover. If you do have a sub, then set the mains to small, and set the crossover at 100hz (since the 2600's have a frequency response starting at 90hz, and there's a slope involved in the crossover setting). It couldn't hurt to also try 120hz and compare the two to see which one you like more.

I have a Yamaha sub and it's at 60Hz and the speakers on the 2600's are 90Hz so Which setting in the onkyo do I set the cross over setting to?

#4 of 8 Robert_J

Robert_J

    Lead Actor

  • 8,046 posts
  • Join Date: Aug 22 2000
  • Real Name:Robert
  • LocationMississippi

Posted July 08 2012 - 10:59 AM

I have a Yamaha sub and it's at 60Hz

What's at 60hz? The dial on the back of the sub?

speakers on the 2600's are 90Hz

What do you mean by that?

#5 of 8 kenkraly20212

kenkraly20212

    Agent

  • 45 posts
  • Join Date: May 26 2012

Posted July 08 2012 - 11:40 AM

I have a Yamaha sub and it's at 60Hz

What's at 60hz? The dial on the back of the sub?

speakers on the 2600's are 90Hz

What do you mean by that?

The speakers I have are 90 hz and the sub is 60hz theirs only a volume control on it and a on off switch. Again I ask what is the cross over on my onkyo TX SR-308 I set the speakers to? I have small speakers which those Yamaha's are.

#6 of 8 gene c

gene c

    Producer

  • 5,655 posts
  • Join Date: Aug 05 2003
  • Real Name:Gene
  • LocationBay area, Ca

Posted July 08 2012 - 12:09 PM

I'd set the crossover to 120. Even though the speakers are rated down to 90 hz they only have 2 1/2 inch drivers. Better to be safe than sorry.
"Everyday room": Panasonic 58" Plasma, Dish HD DVR, Pioneer Elite vsx-23, BDP-23 BR, dv58avi universal dvd player, Paradigm Studio 20 V1, CC-450, Dayton HSU-10 subwoofer.

"Movie/Music room": Toshiba 65" DLP, Dish HD receiver, Marantz 7005, CC-4003, BD-7006, Polk LSI25's-LSi7's-LSiC, 2 original Dayton 10" "Mighty-Mites" subwoofers. (subject to change without notice).

Also have  MB Quart Vera VS05 +.....too much to list. Help me.






#7 of 8 Al.Anderson

Al.Anderson

    Screenwriter

  • 2,118 posts
  • Join Date: Jul 02 2002
  • Real Name:Al

Posted July 08 2012 - 12:21 PM

I have a Yamaha sub and it's at 60Hz and the speakers on the 2600's are 90Hz so Which setting in the onkyo do I set the cross over setting to?

Change the receiver crossover to 100 or 120, and set the sub crossover to 'off', 'out', or it it doesn't have either of those, whatever the highest setting is. If you are using the receiver to control the crossover then you don't want or need the sub doing anything.

#8 of 8 kenkraly20212

kenkraly20212

    Agent

  • 45 posts
  • Join Date: May 26 2012

Posted July 08 2012 - 01:19 PM

Thanks for the help everyone I set the cross over to 120Hz in my onkyo and all the speakers sounds great.
